Name: SMD3535 P5 P6 Outdoor LED Display 6mm Pixel Video Wall
Brand: SHENZHEN KAILITE OPTOELECTRONIC TECHNOLOGY CO., LTD
SKU: شاشة LED خارجية P6
Price: 400.00 USD
Availability: InStock

منزل المنتجات خارجيّ يعلن led عرض

SMD3535 P5 P6 Outdoor LED Display 6mm Pixel Video Wall

تفاصيل المنتج:

مكان المنشأ:	قوانغدونغ ، الصين
اسم العلامة التجارية:	kailite p5 P6 outdoor led display
رقم الموديل:	شاشة LED خارجية P6

شروط الدفع والشحن:

الحد الأدنى لكمية:	3

اتصل

مفصلة وصف المنتج

Pixel Pitch:	6 مم	حجم الوحدة:	192 ملم * 192 ملم
مصباح LED:	SMD3535	وضع القيادة:	قيادة مستمرة 1/8 فحص
قوة الوحدة:	35W	كحد أقصى استهلاك الطاقة:	900W
الكثافة المادية:	27777DOTS/متر مربع	تكوين بكسل:	1R1G1B
قرار الوحدة النمطية:	32*32	مسافة المشاهدة الموصى بها:	6-70 م
زاوية مشاهدة:	H: 120°؛ V:120°	متوسط استهلاك الطاقة:	460 واط
حجم مجلس الوزراء:	960*960mm	وزن الخزانة:	35 كجم/لوحة
درجة حرارة التشغيل:	-30 درجة مئوية ~ + 45 درجة مئوية
إبراز:	SMD3535 outdoor LED display,P5 P6 LED video wall,6mm pixel outdoor display , P5 P6 LED video wall , 6mm pixel outdoor display

Shenzhen Factory RGB Fixed Installation for SMD3535 P5 P6 Outdoor LED Display

Product Specifications

Attribute	Value
Application	Outdoor
Use	Advertising, retail stores, shopping malls, exhibitions, wayfinding, airports, subways, restaurants, hotels, education
Pixels	6MM
Color	Full color
Module size	192mm*192mm
LED lamp	SMD3535
Driving mode	Constant Driving 1/8 Scan
Module power	35w
Max power consumption	900w
Specification	Video Wall

Product Overview

LED technology has revolutionized visual displays worldwide. As a premier application of this technology, our LED screens deliver exceptional visual experiences across diverse environments, transforming spaces with vibrant colors and dynamic content.

SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD specializes in manufacturing high-quality LED displays. We offer customized solutions with competitive pricing and guaranteed quality, ready to meet your specific requirements.

Key Features

Customized solutions tailored to your specific needs
Direct factory pricing with quality assurance
Energy-efficient and environmentally friendly design
Simple installation and easy maintenance
Enhanced heat dissipation with specially designed vent fans

Technical Specifications Comparison

Parameter	P5 Model	P6 Model
Pixel Pitch	5mm	6mm
Use Environment	Outdoor	Outdoor
Module Size	160*160mm	192*192mm
Pixel Density	40,000 dots/m²	27,777 dots/m²
LED Chip	SMD3535	SMD3535
Module Resolution	32*32	32*32
Module Power	30w	35w
Viewing Distance	5-45m	6-70m
Viewing Angle	H:120° V:120°	H:120° V:120°
Max Power Consumption	850w	900w
Ingress Protection	Front:IP67; Back:IP65	Front:IP67; Back:IP65
Lifetime	>100,000 Hours	>100,000 Hours
